Description:
Colloid Mill Products is a fine-fluid materials processing machinery. It Combines a homogenizer, ball mill, three roll machine, shearing machines,Mixers and other machinery of a variety of performance, with excellent ultra grinding, emulsification, homogenization, mixing and other effects. Materials through processing, the particle size of 2 to 50 microns, more than 90% homogeneity, is the ideal equipment for processing of ultrafine particles.
Details:
Specification:
|
Model |
JMS-50 |
JMS-80 |
JMS-110 |
JMS-130 |
JMS-180 |
JMS-240 |
JMS-300 |
|
|
Final size of products |
2-50 |
|||||||
|
Capacity ( t/h)
|
0.005-0.03 |
0.1-0.5 |
0.3-1.2 |
0.4-2.0 |
0.8-6.0 |
4.0-12 |
6.0-25 |
|
|
Main power KW |
1.5/1.1 |
4 |
7.5 |
11/15 |
18.5/22 |
37/45 |
75/90 |
|
|
Dimension |
Length mm |
520 |
685 |
700 |
975 |
981 |
1319 |
1440 |
|
Width mm |
250 |
335 |
430 |
456 |
476 |
500 |
630 |
|
|
Height mm |
555 |
928 |
1000 |
1054 |
1124 |
1276 |
1420 |
|
|
Weight (kg) |
70 |
210 |
300 |
400 |
420 |
1000 |
1600 |
|
