1. Most of the air is circled inside the oven, with high hot efficiency, and the energy can be saved.
2. The role of the use of forced ventilation, adjustable sub-box with the wind plates, the dry materials evenly.
3. Heat source can be steam, hot water, electricity, far infrared, having a wide choice.
4. The noice of our machine is small and low, also having features of temperature control, easy installation and maintenance and balance reunning.
5. Using our machine can dry a lot of materials, can meet your different needs.
1.adopting hot air diffuser device with high performance of diffusing hot are evenly to keep the plastic dry evenly and increase the dry efficiency.
2. Special bend design of hot-blast main avoids the accumulation of dust at the bottom of the tubular electric heating element and also avoids the fire.
3. Inner hopper and all the internal parts are med of stainless steel.
|
Model No.L |
PH12C |
PH-14C |
|
Drying capacity for each time(kg) |
50 |
100 |
|
Power (kw) |
0.45 |
0.45 |
|
Steam to be consumed(kg/h) |
9 |
15 |
|
Air capacity (m³/h) |
3000 |
3400 |
|
Temperature between the top and the bottom(°C) |
±2 |
±2 |
|
Plate for each machine |
24 |
48 |
|
Machine Size |
1400*1200*2000 |
2300×1200×2300 |
|
Detail |
Single door |
Double door |
