Use:
Its extruder, barrel and screw are treated with high quality alloy steel, nitrized and precise. Therefore, in good hardness, corrosion resistance. The specially designed screw is the sound quality of plasticizing, which can help to increase production capacity. Suitable for blown plastic film low density polyethylene (LDPE), high density polyethylene (HDPE) and linear low density polyethylene (LLDPE). It is widely used in the production of food packaging bags, clothing bags, vest bags, garbage.
(the equipment is made between 10 and 55 centimeters, with all sizes adjustable)
Performance: suitable for blowing low-density polyethylene (LDPE), high-density polyethylene (HDPE) and linear low-density polyethylene (LLDPE) plastic film.
| Model | PH-SJ50/FM600 |
| Screw diameter |
50mm |
| Screw L/D Ratio | 30:1 |
| Screw speed | 10-120rpm |
| Mold head specification | 50mm (according to customer needs) |
| Die head structure | inner spiral, center feed |
| Die head material | 45 # machine head with hard chrome |
| Product thickness | 0.008-0.10 mm |
| Width of products | 100 -- 600mm |
| Main motor power | 11KW 4 stage three-phase asynchronous motor inverter control |
| Heating power | 12KW |
| Maximum yield | 35-48kg/h (based on thickness and width) |
| Total weight | 2.5 tons |
| Dimensions | 4500 * wide 2200 * high 3800mm |
