System |
Item |
Unit |
Basic Parameters |
|
Basic |
Plastic fit for |
|
PE/PP |
|
Max hollow product volume |
L |
1L |
|
|
No. of Die head |
SET |
2 |
|
|
Size(LxWxH) |
M |
3.6*2.5*2.4 |
|
|
Weight |
TON |
5 |
|
|
Production Capacity |
Pc/Hr |
400-500 |
|
|
No. of Working Station |
Set |
2 |
|
|
Molds |
Clamping Force |
KN |
120 |
|
Extrusion System |
screw diameter |
MM |
75 |
|
Screw L/D ratio |
L/D |
25:1 |
|
|
Screw fan's power |
KW |
0.56 |
|
|
Extrusion motor's power |
KW |
18.5 |
|
|
Die head |
Die head heating zone |
zone |
2 |
|
Die head heating power |
KW |
13.5 |
|
|
Sprue-die dia.(max) |
mm |
180 |
|
|
Power |
General Power |
KW |
65.7 |
|
Oil-pump motor power |
KW |
7.5 |
|
|
Compressed air |
m³/min |
0.5—0.6 8KG |
|
|
Cooling water |
L/min |
3--5 |
