Brief introduction
1, This machine can be used to cut the bone,meat bone,and frozen meat,and frozen fish.it also can be used to cut the rids.
2, According to your raw material,you should correctly choose corresponding saw wheel.
3. The saw wheel life is depended on the cutting product and pressure.
4. As a standard saw wheel,and it is expected to cut 1000kg to 2000 kg of product.
5. For the fresh meat without the bone,can choose the corrugated saw belt/wheel.So this saw wheel will have more long life.Because you can use the other side of the saw wheel after turning out.
6. This machine have two kinds of material can be choosed, stainless steel or aluminium alloy


Advantage
1. Delicate appearance,high security.
2. Use the Imported high quality saw blade,have the high efficiency and more long life.
3. The machine is equiped with high quality motor,have more stable performance.
4. Low noise,big operation desk,and with sawing thickness adjustment device.
5. Non-slip feet at the bottom of the machine.
Technical parameter of bone cutting machine:
|
Model |
PH-250J |
PH-250G |
|
Voltage |
220v 50hz |
220v 50hz |
|
Power |
750w |
1100w |
|
Table size |
480*380mm |
480*380mm |
|
Saw working speed |
18m/s |
18m/s |
|
Saw length |
1650mm |
1650mm |
|
Saw thickness |
0.55mm |
0.55mm |
|
waterproofing grade |
2 |
2 |
|
Material |
aluminium alloy |
201 SS |
|
Cutting thickness |
4-180mm |
4-180mm |
|
Cutting height |
0-220mm |
0-220mm |
|
Dimension |
500*500*890mm |
500*520*880mm |
|
Weight |
36.7kg |
47.5kg |
